Red D-ring shackle with gray base, used for lifting and securing loads safely.

Crosby S-265 Forged Link

SKU: GRRRR90 Category: Lifting Points

Product details

Widely used on farm machinery, trucks, steel hulled marine vessels and material handling equipment.
Forged link and bracket — Quenched & Tempered.
Excellent welding qualities.
Reference American Welding Society specifications for proper welding procedures.

Videos

S-265 Forged Link

Working Load Limit (lb)		Stock No.	Weight Each (lb)	Dimensions (in)
Design Factor 5:1	Design Factor 4:1			A	B	C	D	F	G	H
											2200	2600	1290839	0.90	1.70	1.58	3.11	1.42	0.51	2.72	1.50
											5500	7050	1290848	1.80	1.93	1.89	3.78	1.62	0.71	3.35	1.73
											9250	11650	1290857	3.30	2.21	2.40	5.04	1.89	0.87	3.94	2.48
											14100	17600	1290866	6.00	2.88	2.88	5.95	2.56	1.02	4.92	2.88
											26450	33050	1290875	13.0	3.94	3.54	7.64	3.55	1.34	6.62	3.74

Working Load Limit (t)		Stock No.	Weight Each (kg)	Dimensions (mm)
Design Factor 5:1	Design Factor 4:1			A	B	C	D	F	G	H
											1	1.2	1290839	0.40	43	40	79	36	13	69	38
											2.5	3.2	1290848	0.80	49	48	96	41	18	85	44
											4.2	5.3	1290857	1.50	56	61	128	48	22	100	63
											6.4	8	1290866	2.70	73	73	151	65	26	125	73
											12	15	1290875	5.90	100	90	194	90	34	168	95
