Red industrial lifting hook with safety latch and load capacity information. Ideal for construction and rigging purposes.

Crosby 385B, 390B Blocks

SKU: GRRR310 Category: Blocks

Product details

New style blocks feature higher working load limits.
Painted or galvanized steel with replaceable wood bumpers.
Side plate opens for insertion of wire rope.
Incorporates exclusive bolt retaining spring to assure no lost bolts, plus utilizes secondary retaining pin.
Bronze bushed sheaves with large bearing diameter for extended block life.
Utilizes Crosby "N" style hooks with integrated latch.
Lubricated center pin.
10" and 12" sizes utilize steel sheaves.
Meets or exceeds all requirements of ASME B30.26. Importantly, these blocks meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.

Videos

385B, 390B Blocks

Block Size (in)	Fitting	Wood Shell		Steel Shell		Sheave Diameter (in)	Manila Rope Size (in)	Working Load Limit (Tons)	Weight Each (lb)
		385-B Stock No. S.C.	385-B Stock No. Galv.	390-B Stock No. S.C.	390-B Stock No. Galv.
										6	T	702000	702108	702216	702324	3.00	3/4 - 7/8	2	7
										8	T	702009	702117	702225	702333	4.00	1 - 1-1/8	4	13
										10	T	702018	702126	702234	702342	6.00	1-1/4	8	28
										12	T	702027	702135	702243	702351	8.00	1-1/2	8	34
										6	J	702036	702144	702252	702360	3.00	3/4 - 7/8	2	7
										8	J	702045	702153	702261	702369	4.00	1 - 1-1/8	4	13
										10	J	702054	702162	702270	702378	6.00	1-1/4	8	28
										12	J	702063	702171	702279	702387	8.00	1-1/2	8	34
										6	G	702072	702180	702288	702396	3.00	3/4 - 7/8	2	7
										8	G	702081	702189	702297	702405	4.00	1 - 1-1/8	4	13
										10	G	702090	702198	702306	702414	6.00	1-1/4	8	28
										12	G	702099	702207	702315	702423	8.00	1-1/2	8	34

Block Size (in)	Fitting	Wood Shell		Steel Shell		Sheave Diameter (mm)	Manila Rope Size (mm)	Working Load Limit (t)	Weight Each (kg)
		385-B Stock No. S.C.	385-B Stock No. Galv.	390-B Stock No. S.C.	390-B Stock No. Galv.
										6	T	702000	702108	702216	702324	76.2	19 - 22	1.8	3.18
										8	T	702009	702117	702225	702333	101.6	26 - 29	3.6	5.90
										10	T	702018	702126	702234	702342	152	32	7.3	11.3
										12	T	702027	702135	702243	702351	203	38	7.3	15.4
										6	J	702036	702144	702252	702360	76.2	19 - 22	1.8	3.18
										8	J	702045	702153	702261	702369	101.6	26 - 29	3.6	5.90
										10	J	702054	702162	702270	702378	152	32	7.3	11.3
										12	J	702063	702171	702279	702387	203	38	7.3	15.4
										6	G	702072	702180	702288	702396	76.2	19 - 22	1.8	3.18
										8	G	702081	702189	702297	702405	101.6	26 - 29	3.6	5.90
										10	G	702090	702198	702306	702414	152	32	7.3	11.3
										12	G	702099	702207	702315	702423	203	38	7.3	15.4

Fitting Type : T - Swivel Latch Hook; J - Yoke and Oblong Swivel Eye; G - Yoke and Swivel Shackle
